Hanutech 4CH RCA Audio To Fiber Extender, Audio Optical Media Converter, FC Optical Interface Transmission Upto 20KM- 1 Year Warranty
Hanutech 4CH Audio (RCA) To Fiber Converter support 1-4 channels Audio (RCA) one way over one single-mode fiber optic, working distance up to 20Km. It can be transmitted at real-time synchronization, no distortion. Adopt all-digital uncompressed transmission technology, To ensure high-quality signal transmission. You can visually detect power, SNYC (fiber) light signals, audio signals on the state of the panel. MTBF (Mean Time Between Failure) is more than 100,000 hours ,Reliable quality. Specification 1.Connector :RCA 2.Input Impedance :600 ohm47K (balanceun balance) 3.Output Impedance :600 ohm10K (balanceun balance) Max input output voltage :2.0Vp-p 4.Frequency response:20HZ-20KHZ 5.Audio sample rate :48KHZ 6.SNR ≥88dB 7.Suitable fiber Single-mode fiber Wavelength 1310nm1550nm 8.Transmission distancesingle-mode 0 ~ 20 km (Multimode available custom) 9.Power supply AC100~240V, DC5V2A Applicable environment 1.Intercom System 2.Public Broadcasting System 3.Intelligent Traffic Monitoring System (ITS) 4.Security system 5.TV medical care 6.Remote multimedia teaching campus monitoring 7.TV and telephone conference 8.Long-distance radio and television transmission system
